DALI 48VDC 250W 5.2A ERP0.5W IP66 Constant Voltage Dimmable Signal Driver

Model NO.
SD-DALI KAV-48250-O-P3
Delivery:
EXW
Country of Origin:
CHINA
Quantity:
  • Model:SD-DALI KAV-48250-O-P3
  • Dimming Signal : DALI
  • IEC Standard: IEC62386
  • Size:282*90*45mm
  • Dimming Range:0-100%
  • Frequency:50/60Hz
  • Input Voltage:100-250V
  • Output Voltage:48V
  • Output Power:250W
  • Output Current:5.2A
  • IP:66
  • ERP:0.5W
  • Place of Origin:CN;GUA
  • Warranty(Year):3 years
  • Brand Name:KEYTEC
  • 1
  • Product Description:
    Product Model:SD-DALI KAV-48250-O-P3
    Input Voltage:AC 100-250VSignal Standard:DALI    IEC-62386
    Output Voltage:DC 48VHousing Material:Aluminum
    Output Current:5.2ASize(mm):282×90×45
    Output Power:200W MaxNet Weight:2400g
    Work Efficiency:86%(80% load)Vibration Frequency:50 Hz to 60 Hz
    PF:0.95Dimming Range:0-100%
    IP:66Dimming Effect:Smooth, No flash, No jitter
    Operating Temperature:-25° C~50 ° CCertificate Information:ERP.SELV,SGS,CE,SAA,RoHS
    Protections:Short circuit / Overload / Temperature protectionERP:0.5W
    OEM Service:Yes

    Warranty:

    3 years
    DALI Features
