3in1 0-10V&1-10V&100K 550mA 28W 25-42VDC IP20 Constant Current Dimmable Driver

Model NO.
KMD-28-10V-E1
Delivery:
EXW
Country of Origin:
CHINA
Quantity:
  • Size:D80*30mm
  • Dimming signal:3in1 0-10V&1-10V&100K
  • Certificate:CE CB SAA
  • Warranty:3 Years
  • OEM&ODM Service:Yes
  • ERP: 0.5W
  • PF:0.95
  • IP:20
  • Net Weight:150g
  • Output Power:28W
  • Output Type:Single
  • Input Voltage:220-240V AC
  • Place of Origin:CN;GUA
  • Warranty(Year):3 years
  • Brand Name:KEYTEC
  • Model Number:KMD-28-10V-E1
  • Output Frequency:50/60Hz
  • Output Current:650mA


Product Description
Product Model:KMD-28-10V-E1 [28W 650mA]
Input Voltage:220-240VDimming Function:0/1-10V
Output Voltage :25-42VDimming Range:1-100%
Output Current:650mAMaterials:Plastic
Output Power:28W MAXDimming Effect:Smooth, no flash, no jitter
Size(mm):D80×30Protections:

Short circuit / Overload /

Over Temperature

Vibration Frequency:50 Hz to 60 HzOperating Temperature:-20 º C to +45
Work Efficiency:85%(80% load)ERP:0.5W
PF:0.95Certificate Information:CB,CE,SAA
IP:20Warranty:3 Years
Product Photo
